Introduction

The Result Charts tab displays the data of the Result Table tab differently. It graphically visualizes these performance measures, allowing you to easily compare multiple cases with one another in a blink of an eye.

This tab makes putting a report together that little bit easier.

Region temperatures

In the 'Region Temperatures'-area, three charts stand side by side and display respectively the maximum, mean, and minimum temperatures of all the regions.
You have the freedom to pick the units you prefer, between Kelvin (K), degree Celsius (°C), or degree Fahrenheit (°F). By hovering over a bar, you can see the exact temperature of the region.

Boundary temperatures

The same graphs are also shown for each of the boundary patches. Three charts stand side by side and display respectively the maximum, mean, and minimum temperatures of all the boundaries.
You have the freedom to pick the units you prefer, between Kelvin (K), degree Celsius (°C), or degree Fahrenheit (°F). By hovering over a bar, you can see the exact temperature of the boundary.

Pressure

The final chart displays the pressure values at all the fluid boundaries that your case contains. You can choose between units of pascal (Pa), bar (bar), and pound per square inch (PSI). You can also hover over the bars to get the exact pressure values of the boundary of interest.
